2) Twelve principles of animation
Twelve principles of animation
- Stretch and shrink
- Anticipation
- Staging
- Direct animation
- Complementary
- Accelerate and decelerate
- Arcs
- Secondary action
- Synchronization
- Exaggeration
- Solid drawing
- Attractive
That … is a lot. And I’m not really an animator. But let’s see what we can do!
let gui;
let params = {
stretchAndShrink: false,
anticipation: false,
staging: false,
directAnimation: false,
complementary: false,
accelerateAndDecelerate: false,
arcs: false,
secondaryAction: false,
synchronization: false,
exaggeration: false,
solidDrawing: false,
attractive: false,
};
function frameCycle(cycleLength, offset) {
let t = ((frameCount + (offset || 0)) % cycleLength) / cycleLength;
return t < 0.5 ? t * 2 : 2 - t * 2;
}
function setup() {
createCanvas(400, 400);
background("white");
gui = createGuiPanel('params');
gui.addObject(params);
gui.setPosition(420, 0);
}
function draw() {
stroke("white");
fill(0);
let arcPhase = frameCycle(60);
let groundPhase = 1 - arcPhase;
let xPhase = frameCycle(600);
let yPhase = arcPhase;
// Accelerate / Decelerate. as we're going left/right
if (params.accelerateAndDecelerate) {
let cycle = frameCount % 600;
let goingRight = cycle < 300;
if (goingRight) {
xPhase = pow(xPhase, 0.5); // speed up
} else {
xPhase = pow(xPhase, 2.0); // slow down
}
}
let x = xPhase * width;
let y = height * 3 / 4 - (height / 2) * yPhase;
// Arcs (horizontal sway)
if (params.arcs) {
x += sin(yPhase * PI) * 40;
}
let baseRadius = width / 6;
let w = baseRadius;
let h = baseRadius;
// Stretch & Squash (ground contact)
if (params.stretchAndShrink) {
let squashiness = 1 + 0.6 * pow(groundPhase, 4);
w *= squashiness;
h /= squashiness;
y += (baseRadius - h) * 0.5;
}
// Anticipation (hang time at top, exaggerated drop)
if (params.anticipation) {
// invert easing so it slows near the top
let t = 1 - arcPhase;
let eased = 1 - pow(t, 3); // slow at top, fast downward
y = height * 3 / 4 - (height / 2) * eased;
}
// Exaggeration
if (params.exaggeration) {
w *= 1.4;
h *= 0.6;
}
// Solid Drawing (fake volume via outline weight)
if (params.solidDrawing) {
background("white");
fill("white");
stroke("white");
} else {
fill("black");
stroke("white");
}
// Staging (center bias)
if (params.staging) {
x = width / 2;
}
// Direct Animation (mouse-driven influence)
// I'm already keyframing, so I just took it literally :)
if (params.directAnimation) {
let mx = (mouseX - width / 2) * 0.1;
let my = (mouseY - height / 2) * 0.1;
x += mx;
y += my;
}
// Secondary Action (small orbiting detail)
if (params.secondaryAction) {
let sx = x + cos(frameCount / 20) * w * 1.4;
let sy = y + sin(frameCount / 20) * h * 1.4;
ellipse(sx, sy, w * 0.25, h * 0.25);
}
// Synchronization (bounce timing matches squash)
if (params.synchronization) {
// sync horizontal + vertical timing
let syncFactor = sin(frameCount / 10); // smooth oscillation
w *= 1 + 0.3 * syncFactor;
h /= 1 + 0.3 * syncFactor;
// adjust y to stay grounded
y += (baseRadius - h) * 0.5;
}
// Attractive (subtle harmonic proportions)
// 'cause the golden ratio is attractive or something
// What do you want from me? There are *12* of these on day 2...
if (params.attractive) {
let ratio = 1.618;
if (w > h) {
h = w / ratio;
} else {
w = h / ratio;
}
}
ellipse(x, y, w, h);
if (params.complementary) {
ellipse(x, height - y, w, h);
}
}
